smart window film
Product Attributes :Brand Name: Homewell
Product Name: Smart Film Switchable
Application:Hotel, Villa, Office Building, Hospital, School, Supermarket, Workshop
Function:Decorative Glass, privacy protection,heat insulation,explosion proof,decorative
Technique:Clear Glass, Tempered Glass, Smart Glass
Material:PDLC
Feature:self-adhesive
Thickness:0.44mm
Standard width:≤14cm/14-18cm
Length:customize
Working voltage:AC48V~65V/50Hz
Power consumption:≤5W/㎡
Lifetime:>80000h
1.The structure ad principle of HOMEWELL PDLC smart glass(Film)
1.1Structure
（1）Structure diagram：
HOMEWELL Switchable Transparent Glass , refered to as STG, this product is made by the dry process of gluing glass, and the switchable transparent film(STF) is glued between two pieces of glass。 The glass meets the national standard for laminated standard.、
(2) Exterior structurel dimensions：
Glass thickness +0.76mm（EVA）+0.44mm PDLC film+0.76mm（EVA）+ Glass thickness(Glass thickness:3mm-20mm)
Note: Tpye of glass: super wihte, white, fireproof, Low-E coated glass etc.
1.2.Principle:
STF is the core technology of light-proof glass developed and products of our company. Magic glass, Switchable Light Glass, Smart Window, Intelligent Smart Glass, Chromotropic glass, Electric fog glass is the same products. The atomization function of the HOMEWELL Glass is realized by the PDLC smart film of the interlayer.
| Items | ||
| Thickness | Total thickness (without protective film) | 0.47mm |
| PDLC | 03.8mm | |
| AB glue | 90μm | |
| PE protective film | 35μm | |
| PET release film | 50μm | |
| Sheet | Width | 1000,1200,1500,1800(mm) |
| Length | According to customer requirements | |
| Roll | Width | 1020,1220,1520,1850(mm) |
| Length | ≤ 50m/Roll | |
| Roll tube | Inner Diameter |
