Product Attributes :Brand Name: Homewell
Product Name: Smart Film Switchable
Application:Hotel, Villa, Office Building, Hospital, School, Supermarket, Workshop
Function:Decorative Glass, privacy protection,heat insulation,explosion proof,decorative
Technique:Clear Glass, Tempered Glass, Smart Glass
Material:PDLC
Feature:self-adhesive
Thickness:0.44mm
Standard width:≤14cm/14-18cm
Length:customize
Working voltage:AC48V~65V/50Hz
Power consumption:≤5W/㎡
Lifetime:>80000h
3. Application
Large command and control dispatch center office, meeting room, negotiation room, special hospital room. Operating room, villa toilet. Shower room, window of entertainment room. Isolation. screen, etc..
Police station, Courts. Prisons. Jewelry shops. Museums. Bank Windows. Curtain walls. Counter. Isolation, etc.. Large special screen projection screen, etc..
4.HOMEWELL Self-adhesive PDLC film performance and feature
The self-adhesive electrical control film(Called HOMEWELL Self-adhesive film) is a new type of product based on the PDLC-Film dispersed polymer liquid crystal electric control film(referred to as the PDLC film). In addition to maintaining the characteristics of PDLC-Film's original "power transparent, power outage grinding", the electric control membrane also has the characteristics of "dry direct paste, automatic exhaust"; Compared with the traditional glass made using adhesive technology, it has the advantages of "light weight and simple installation". It provides the best solution for some projects that have been installed with ordinary glass or need to be projected on ordinary glass. The entire glass facility, Can be directly pasted on the smooth surface of the clean glass. It is one of the best options to realize the fast switching and hiding space of glass partition wall; It can also be used as a backseat screen and has a unique effect in window advertisements and exhibition displays. Car glass side window, rear block and skylight glass applications.
5.HOMEWELL self-adhesive Technical indicators and parameters
1.Structure of HOMEWELL Self-adhesive: ITO conduction powder+ (macromolecule polymer r+ liquid crystal)mixture+ ITO conduction powder
2.1 Optical property
1) Parallel optical transmittance( Power on): >75%
Parallel optical transmittance( Power off): ≤2%
2) Visible Light Transmittance( Power on): ≥85%
Visible Light Transmittance(Power off): >60%
3) View angle(Power on): ≥145º
4) Haze( Power on): <4%
Haze( Power off): ≥96%
5)Response time: Off-On <10ms
2.2 Physical property
1) Working environmental temperature:-20℃ ~ + 60℃
2)Storage environmental temperature:-30℃ ~ +70℃
3)Size: Width:1500mm* length is unlimited
2.3 Electrical property
1)Drive voltage:
Input voltage: AC220V、AC110V、DC24V、DC12V
Working voltage: AC48V~65V/50Hz
2) Threshold voltage: ≤25V(Smallest power of voltage)
3)Power consumption: ≤5W/㎡
4) Reponse time:
Turn on time: <10ms
Turn off time: <10ms
5)Working life(Power on): >80000h
6)Switch time:(Power on-off):>2000000 times
7)Insulation resistance:>20MΩ
8)Frequency:30Hz~400Hz(The besst working frequency is 50-100 Hz)
2.4 Exterior quality:
1)Thickness: 0.4mm
2)Scoring: NO
3)Air bubble: No
4)Impurity: NO
5)Chip,unglued,side opening: NO
Photoelectric Performance | Classic self-adhesive smart film | ||
Items | ON/OFF | Test Methods/Standards | |
Operating voltage | ON | 60V | Multimeter/ Voltage Regulator,WGW |
Power consumption | ON | ≤ 5W/m² | Multi-parameter electric measuring instrument |
Viewing angle | ON | ≥ 160° | Visual Inspection |
Uv blocking rate | OFF | ≥ 99% | Optical transmittance tester |
Infrared blocking rate | OFF | ≥ 60% | |
Response time | OFF→ON | ≤ 30ms | Liquid crystal parameter |
ON→OFF | -30°C ~ 85°C | integrated tester | |
Operating temperature | -- | -30°C ~ 85°C | constant temperature and humidity testing machine |
Lifetime | -- | 10 -15 years | GB18910.5-2008 |
Switching times | -- | ≥2 million times | Self-made on/off tester |
