Product Attributes :Brand Name: Homewell
Product Name: Smart Film Switchable
Application:Hotel, Villa, Office Building, Hospital, School, Supermarket, Workshop
Function:Decorative Glass, privacy protection,heat insulation,explosion proof,decorative
Technique:Clear Glass, Tempered Glass, Smart Glass
Material:PDLC
Feature:self-adhesive
Thickness:0.44mm
Standard width:≤14cm/14-18cm
Length:customize
Working voltage:AC48V~65V/50Hz
Power consumption:≤5W/㎡
Lifetime:>80000h
(1)Opaque statue of STG
STG is composed of two transparent ITO film sandwiched between a layer of plastic and liquid crystal. The plastic and liquid crystal include a liquid crystal ball and a polymer, and the liquid molecule director is approximately parallel to the glass substrate , the polymer is surrounded by the liquid crystal micro droplet, the refractive index of the polymer is np , which is similar to the refractive index of the glass. Approximately 1.5 , an is isotropic substance, the unusual refractive index and the ordinary refractive index of liquid crystals are ne and n, respectively. When the vertically incident visible light passes through the glass and transparent ITO film ,it enters the liquid crystal sphere and the scattering occurs and the STG is atomized.
(2)Transparent STG
When the external electric field is applied, the electric field is formed between the two transparent ITO films, and the liquid crystal molecules are arranged in the direction of the electric field. When the vertically incident visible light passes through the glass and the transparent ITO film, it is incident to the interface between the liquid crystal sphere and the polymer. Because the no direction is perpendicular to the direction of light propagation and no is equal to np, the glass is transparent.
(3)STG haze
The main indicator of the advantages and disadvantages of STG glass optical performance is transparency. In fact, it is the haze. The smaller thaze when energized, the better haze when the power is cut off. When the external electric field is applied, the light is perpendicular to the direction of the transparent conductive film. When incident, although nLC is approximately equal to no, However, due to the difference between the nP and no values, scattering still occurs at the interface between liquid crystal droplets and polymers. This is the main reason for the haze.
(4)View angle
When the ITO film is power on, Angle between incident light and the vertical direction of the electric control film is not zero(Called the view angle “a”) The direction of light propagation in the STF is not parallel to the liquid crystal molecule pointing vector, as shown in the figure:
Photoelectric Performance | Classic self-adhesive smart film | ||
Items | ON/OFF | Test Methods/Standards | |
Operating voltage | ON | 60V | Multimeter/ Voltage Regulator,WGW |
Power consumption | ON | ≤ 5W/m² | Multi-parameter electric measuring instrument |
Viewing angle | ON | ≥ 160° | Visual Inspection |
Uv blocking rate | OFF | ≥ 99% | Optical transmittance tester |
Infrared blocking rate | OFF | ≥ 60% | |
Response time | OFF→ON | ≤ 30ms | Liquid crystal parameter |
ON→OFF | -30°C ~ 85°C | integrated tester | |
Operating temperature | -- | -30°C ~ 85°C | constant temperature and humidity testing machine |
Lifetime | -- | 10 -15 years | GB18910.5-2008 |
Switching times | -- | ≥2 million times | Self-made on/off tester |
